A mist blower is one of the ideal machines for agricultural needs and is used to spray liquids including chemicals and insecticides. This post helps you to know more about the Bonhoeffer mist duster models. We are the leading agriculture and gardening machinery supplier and mist duster is one of the top products of our company. Here is the list of Bonhoeffer mist duster models that you need to know, if you are going to select the premium quality and durable spraying machine.

Bonhoeffer Machines Mister Duster Models with Features

1). MODEL: BON-P-MD42

MAXIMUM POWER: 3HP / 7800R/MIN

MAXIMUM RANGE: 12 M

LIQUID OUTPUT: 0 – 7 L/MIN

FUEL TANK CAPACITY: 1.3L

STARTING SYSTEM: MANUAL

TANK CAPACITY: 20 LITERS

2). MODEL: BON-P-MD52

ENGINE: 4 HP

ENERGY: 6500 R/MIN

FUEL TANK CAPACITY: 1.5 LITERS

STARTING SYSTEM: MANUAL

TANK CAPACITY: 14 LITERS

RANGE (M) : ≥12

SPEED: 6500 ± 320

3). MODEL: BON-P-MD55

ENGINE: 4 HP

ENERGY: 6500 R/MIN

FUEL TANK CAPACITY: 1.5 LITERS

STARTING SYSTEM: MANUAL

TANK CAPACITY: 14 LITERS

RANGE (M): ≥12

SPEED: 6500 ± 320

4). MODEL: BON-P-MD82

MAXIMUM POWER: 5.5HP / 7000R/MIN

MAXIMUM VERTICAL RANGE: 18 M

MAXIMUM HORIZONTAL RANGE: 20 M

LIQUID OUTPUT: 0 – 7 L/MIN

FUEL TANK CAPACITY: 2.0L

STARTING SYSTEM: MANUAL

TANK CAPACITY: 20 LITERS

Elements and Working Process of Agricultural Mist Blower Duster

There are different components of the machine such as a tank, engine, distribution system, nozzles, and pump. All these elements work together for the purpose of atomising the liquid on the crops and plants and distributing it efficiently over the crop. Let’s talk about – how a mist duster works.

The chemical which is in the form of liquid is pressurised by the pump and the response will be sent through a tube to the machine distribution system. After this, the nozzles break it down into very small particles (between 50 to 2000 microns).

The operation of a mist duster machine mainly depends on the atomisation process which consists of breaking up a liquid into very small or micro particles. This process is necessary to ensure an even distribution of the liquid over the surface of the plants.

Conclusion –

A mist duster machine is one of the useful crop protection and management machines for farmers through which they can protect their crops efficiently. The main purpose of this post is to give information on Bonhoeffer mist duster models with features. We are known for our premium quality gardening and agriculture machinery, tools and equipment. After sale
